wedi Top Wall

wedi Top Wall

new

"Ready-to-install elegant, seamless alternatives to traditional tiles that fit perfectly."

Product information

The wedi Top Line combines organic look and timeless design creating a stylish atmosphere in any bathroom. Thanks to its versatility, it is suitable for a wide range of applications for both modern and traditional interiors. Whether as a single accent wall in the shower or a surface design for the entire room, these high-quality textured and patterned surfaces give life and character to any space. A bathroom that boasts style - the wedi Top Line transforms bathrooms into a reflection of the owner’s personality, not only allowing for individual ideas, but creating a unique personal space of wellness.

Hygiene promoting, easy-to-maintain seamless design - the wedi Top Wall is an ideal alternative to traditional tiling and thanks to its large-format, the perfect solution for fast bathroom design. .Choose from 12 different colour options, combine them however you like - the result is always a sleek design where grout lines don't break the design. There is also a high level of security: the walls are waterproof in the overall system and are particularly durable; in case of damage, the natural stone look variants can be repaired almost without any trace!

The wedi Top Line complements the smart wedi system solutions perfectly: thanks to its variety of colours and textures, it offers unique options for designing elegant, seamless bathrooms.

Natural stone look
Inspired by nature – both its look/colour scheme and its feel/structured surface. The 6 mm thick material is completely dyed through, making cut edges invisible.

Monochrome look
The 6 mm thick surface is elegant and simple – with a timeless appearance and silky look. The colours also underline the monochrome impression.

Marble look
For demanding tastes – with a fine matt structure, 4 mm thickness and trendy look. They are replicas of the real thing right down to the last detail, including 70% recycled marble.

Detailed view of wedi Top Wall


Material Mineral and vinyl composite material
Material thickness 6 mm
Weight 9,0 kg/m²
Coefficient of thermal expansion 7.07 x 10-5 K¯¹ (DIN 53752)
Bending strength 80 MPa (DIN 53452)
Ball indentation hardness 260 N/mm² (in accordance with DIN ISO 2039-1)
Tensile strength 45 MPa (DIN 53455)
Continuous temperature resistance up to 70°C (in accordance with DIN EN ISO 13894-1)
Water resistance present
Suitable for underfloor / wall heating yes
Ability to resist temperature changes passed (-50°C/+70°C)
Fire behaviour E (in accordance with EN 13501-1)
Bacterial resistance resistant to mould and bacterial contamination (in accordance with DIN EN ISO 846 A/C), demonstrable reduction of bacteria on the surface (up to 99.9% within 24 hours in accordance with JIT Z 2801)
Chemical resistance resistant to normal household chemicals
Scratch resistance present (see care instructions)
Impact resistance present
Floor impact resistance performance class Performance class 33 for areas with heavy use such as: shop fitting / hotels (in conformity with DIN EN 13329)
Cuttability Can be worked with all common tools, such as a hand-held circular saw. A jigsaw can be used for recesses in the wedi Top Wall for fittings.
Slip resistance B (in accordance with DIN 51097)
Wheel-chair navigability present
Cleanability easy to clean (see care instructions)
Ease of disposal Waste code 170203 construction and demolition waste
Surface quality textured natural stone look
Feel heat-retaining

Product sizes

Order no. Designation Length × Width × Thickness
072042000 wedi Top Wall ready-to-fit surface, natural stone look, stone grey 2.500 × 900 × 6 mm
072042001 wedi Top Wall ready-to-fit surface, natural stone look, stone grey 2.500 × 1.200 × 6 mm
072042100 wedi Top Wall ready-to-fit surface, natural stone look carbon black 2.500 × 900 × 6 mm
072042101 wedi Top Wall ready-to-fit surface, natural stone look carbon black 2.500 × 1.200 × 6 mm
072042040 wedi Top Wall ready-to-fit surface, natural stone look sahara beige 2.500 × 900 × 6 mm
072042041 wedi Top Wall ready-to-fit surface, natural stone look sahara beige 2.500 × 1.200 × 6 mm
072042020 wedi Top Wall ready-to-fit surface, natural stone look concrete grey 2.500 × 900 × 6 mm
072042021 wedi Top Wall ready-to-fit surface, natural stone look concrete grey 2.500 × 1.200 × 6 mm


Material Acrylic resin bonded mineral material
Material thickness 6 mm
Weight 9,6 kg/m²
Coefficient of thermal expansion 5.6 · 10-6 · K¯¹ (in accordance with DIN 53752)
Bending strength 65 N/mm² (in accordance with DIN EN 310)
Ball indentation hardness 260 N/mm² (in accordance with DIN ISO 2039-1)
Tensile strength 37 MPa (in accordance with DIN EN ISO 527)
Continuous temperature resistance up to 70°C (in accordance with DIN EN ISO 13894-1)
Water resistance present
Suitable for underfloor / wall heating yes
Ability to resist temperature changes passed (-50°C/+70°C)
Fire behaviour E (in accordance with EN 13501-1)
Bacterial resistance resistant to mould and bacterial contamination (in accordance with DIN EN ISO 846 A/C), demonstrable reduction of bacteria on the surface (up to 99.9% within 24 hours in accordance with JIT Z 2801)
Chemical resistance resistant to normal household chemicals
Scratch resistance present (see care instructions)
Impact resistance present
Floor impact resistance performance class Performance class 33 for areas with heavy use such as: shop fitting / hotels (in conformity with DIN EN 13329)
Cuttability Can be worked with all common tools, such as a hand-held circular saw. A jigsaw can be used for recesses in the wedi Top Wall for fittings.
Slip resistance A (in accordance with DIN 51097)
Wheel-chair navigability present
Cleanability easy to clean (see care instructions)
Ease of disposal Waste code 170203 construction and demolition waste
Surface quality homogeneous surface
Feel heat-retaining

Product sizes

Order no. Designation Length × Width × Thickness
072042250 wedi Top Wall ready-to-fit surface, Pure white 2.600 x 900 x 6 mm
072042260 wedi Top Wall ready-to-fit surface, Pure white 2.600 x 1.200 x 6 mm
072042251 wedi Top Wall ready-to-fit surface, flake white 2.600 x 900 x 6 mm
072042261 wedi Top Wall ready-to-fit surface, flake white 2.600 x 1.200 x 6 mm
072042252 wedi Top Wall ready-to-fit surface, flake lightgrey 2.600 x 900 x 6 mm
072042262 wedi Top Wall ready-to-fit surface, flake lightgrey 2.600 x 1.200 x 6 mm
072042253 wedi Top Wall ready-to-fit surface, flake grey 2.600 x 900 x 6 mm
072042263 wedi Top Wall ready-to-fit surface, flake grey 2.600 x 1.200 x 6 mm


Material Natural stone-plastic composite material
Material thickness 4 mm
Weight 8.19 kg/m²
Permanent temperature resistance up to 50 °C (according to DIN EN ISO 13894-1)
Dimensional stability <=0.25%
Water resistance is provided
Alternating temperature resistance passed (-50 °C/+70 °C)
Optimal processing temperature 15 °C - 30 °C
Fire behavior C ‑ s1, d0
Chemical resistance Resistant to household chemicals (according to EN 438-2)
Scratch resistance is provided (see care instructions)
Impact resistance is provided
Workability Can be cut with conventional tools, such as a hand-held circular saw. A jigsaw can also be used for cutting recesses into the wedi Top Wall
Slip-rating A (according to DIN 51097)
Wheelchair access not provided
Point load as shower chair not provided
Steam bath suitability not provided
Maitenance Easy to clean (see care instructions)
Disposal Waste key 170203 Construction and demolition waste
Surface finish Durable decorative foil
Feel heat-retaining

Product sizes

Order no. Designation Length × Width × Thickness
072042212 wedi Top Wall marble white 2.600 x 600 x 4 mm
072042210 wedi Top Wall marble white 2.600 x 900 x 4 mm
072042211 wedi Top Wall marble white 2.600 x 1.200 x 4 mm
072042222 wedi Top Wall marble grey-beige 2.600 x 600 x 4 mm
072042220 wedi Top Wall marble grey-beige 2.600 x 900 x 4 mm
072042221 wedi Top Wall marble grey-beige 2.600 x 1.200 x 4 mm
072042232 wedi Top Wall marble grey-brown 2.600 x 600 x 4 mm
072042230 wedi Top Wall marble grey-brown 2.600 x 900 x 4 mm
072042231 wedi Top Wall marble grey-brown 2.600 x 1.200 x 4 mm
072042242 wedi Top Wall marble black 2.600 x 600 x 4 mm
072042240 wedi Top Wall marble black 2.600 x 900 x 4 mm
072042241 wedi Top Wall marble black 2.600 x 1.200 x 4 mm

wedi
In order to display YouTube videos, it is necessary that you accept marketing cookies. Please see our privacy policy for more information. To the cookie settings

Areas of use Top Wall

Installation:
As a 100 % wedi system component, the Fundo Top is bonded onto the already installed Fundo shower element using wedi 610 adhesive and sealant.
wedi Top Wall can be used on all common substrates such as tiles, plaster or plasterboard, among other things, as well as wedi building boards, wedi Subliner sealing membranes and wedi 520 sealant.
The floor and wall surfaces in the wedi Top range can be individually adjusted to the required size and wall surfaces are also easily cut to desired shapes and dimensions thus allow for individual surface designs.

Transport and storage:
These elements should be transported with great care and stored horizontally in the packaging intended for this purpose.

Miscellaneous:
Information concerning care, cleaning and repair can be found in the separate care instructions. These are enclosed with the product and are available online at www.wedi.eu.
