Sanoasa corner seat
Fine detail with a strong impact.

Sanoasa Corner Seat

"Fine detail with a strong impact."

Product information

The innovation is in the detail. The wedi corner seat in a pure triangular shape is available in two sizes and provides you with a relaxing wellness break even in a very small shower.

The wedi Sanoasa corner seat is a floating seat element for individual tiling. It offers added value for all generations and is also perfect for use in small showers thanks to its compact design. Installation can be done both on the raw surface as well as after tiling. • Watertight
• Stable
• Lightweight
• Quick and easy fitting
• Easy to retrofit

Technical data

Technical properties of the Sanoasa corner seat

Sanoasa corner seat element M
Width	600 mm
Depth	300 mm
Thickness	100 mm
Weight	1.10 kg
Sanoasa corner seat element L
Width	800 mm
Depth	400 mm
Thickness	100 mm
Weight	1.25 kg
Technical properties of raw foam building board systems
Long-term compressive strength (50 years) ≤ 2% compression EN 1606	0.08 N/mm²
Compressive resistance or compressive strength at 10% compression EN 826	0.25 N/mm²
Associated module of elasticity EN 826	10 – 18 N/mm²
Thermal conductivity EN 13164	0.036 W/mK
Tensile strength EN 1607	0.45 N/mm²
Shearing resistance EN 12090	0.2 N/mm²
Shear modulus EN 12090	7 N/mm²
Bulk density EN 1602	32 kg/m³
Resistance to water vapour diffusion (μ) EN 12086	100
Water absorption under long-term immersion EN 12087	≤ 1.5 % by vol.
Capillary action	0
Linear coefficient of thermal expansion	0.07 mm/mK
Temperature limits	-50°C / +75°C
Fire behaviour EN 13501	E
Carbon dioxide propellant GWP value	1

Product sizes

Order no.	Designation	Length x width x thickness
073784302	wedi Sanoasa corner seat, size M	600 x 300 x 100 mm
073784402	wedi Sanoasa corner seat, size L	800 x 400 x 100 mm
